Description And features
The Wolf-14 is a high-tech, durable and versatile Night Vision monocular that delivers great performance at a reasonable price. Packed with high-tech features, the Wolf-14 is equally suited for security professionals as it is for hunting and recreation. The Wolf-14 can be hand-held or mounted on a headgear. The Wolf-14 can be used as a goggle system, or stowed out of the line of sight without the need to completely remove it. This device operates with a single operating knob. When used in conjunction with a head or helmet mount, it also includes features such as the flip-up turn off function. With a variety of compatible lenses, long-range nighttime viewing is available in seconds. The Wolf-14 features bright light shut-off circuitry and a built-in IR illuminator. The Wolf-14 can be equipped with high-performance Gen 2 image intensifier tubes in green or white phosphor.
Warning: California's Proposition 65
- Compact, rugged design
- Head mountable for hands-free usage
- Bright light cut-off
- Ergonomic, simple, easy to operate controls
- Utilizes single CR123A Lithium or AA battery
- Built-in Infrared illuminator
- 3-Year warranty
Image Intensifier Tube: Gen 2+ "White Phosphor Level 1"
Magnification: 1x
Lens System: 25 mm; F/1.2
FOV: 42°
- Rhino mount
- J-Arm
- Soft bag
- Lens paper
- Safety/hard case
- User Manual
Specifications
Environment Rating
IP65
Image Intensifier Tube
Gen 2+ "White Phosphor Level 1"
Resolution
51-64 lp/mm
Field of view cleanness by zone
Gen 2 IIT NW1 is the highest resolution and the cleanest offered by AGM. There are practically no visible spots in Zone 1.
Magnification 1x
Lens System 25 mm; F/1.2
FOV 42°
Focus Range 0.25 m to Infinity
Diopter Adjustment -5 to +5 diopters
Infrared Illuminator Yes
Bright Light Cut-Off Yes
Battery Type One CR123A (3V) or one AA (1.5V)
Battery Life (Operating) Up to 40 hours at 20°C (IR off)
Operating Temperature Range -40°C to +50°C (-40°F to +122°F)
Storage Temperature Range -50°C to +70°C (-58°F to +158°F)
Weight 290 g (0.64 lb)
Overall Dimensions 115 × 69 × 54 mm (4.5 × 2.7 × 2.1 in)
Package Includes Rhino mount, J-Arm, Soft bag, Lens paper, Safety/hard case, User Manual.
Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.
Materials
Materials
Shipping & Returns
Shipping & Returns
Dimensions
Dimensions
Care Instructions
Care Instructions
Customer Reviews
Good: The optic itself works well for its price point. it is a good entry level NOD that will get the job done.
Bad: MOUNT SUCKS. Bad. Lock up is not secure and wobbles. Mounted to helmet. Used twice. The tab in the bayonet/horn interface that secures the J-arm into the mount snapped off under the weight of the optic while running. Of course no spare or repair parts listed for it. You can make it work with a Norotos RHNO mount, if you cut and shave parts off of the Norotos mount with a grinder, file and Dremmel, and one strategically placed zip tie. Which i would have preferred not to do, because now this Norotos mount will forever be dedicated to this optic.
End user would be better served if optic had the ability to use other, more robust mounting options and not proprietary components.
Used this unit on night 2 of Scout course after first night of thermal only. Thermal was great for identification of threats but useless for movement. Sitting at the ORP on security with this unit was amazing. Mounted on the Team Wendy helmet it made the Recce course even better than I thought it would be.
I’ve only ever previously used dual tube (aviation PVS 6&9 units) so this is my first using a single monocle system. Initial unboxing and wear around the property just walking around into different environmental lighting appears to be good quality, acuity and clarity. Have not fired weapons with this yet. It does acquire the NS settings on the RDS well. Small amount of “play” in the rhino mount to helmet, I do not currently have a bungee on the mount, I expect that using one will tighten that up.
AGM WOLF-14 NW1
This is a great tool for night vision. The clarity is better than I even hoped for. No, it's not quite as good as the ones that I used as an O5, but it's tons better than what I used as an 02! I am super happy. The price is right and the delivery was quick. I'm not sure what else you could ask for.
